Milwaukee PH28X Punch / 4933396392

Manufacturer

: Milwaukee

Model:

PH 28 X

Warranty:

3 years after registration on the website

Description:

The heavy-duty hammer drill delivers 3.4 joules of impact energy. An 820-watt motor combined with an optimized drilling speed results in unmatched drilling performance. Soft start for precise drilling/chiseling. Low vibration thanks to the ergonomic soft-grip on the main and side handles. Soft-hammer mode for drilling in delicate materials. Best-in-class durability is achieved through the use of integrated metal block technology in the gear mechanism. Brush rotation ring (for the same power in both forward and reverse directions). The safety clutch protects the machine and the user if the drill bit jams. The X version is available with a quick-change FIXTECTM adapter with a keyless chuck. 4 m cable.

Technical specifications:

Blow energy (EPTA) (J): 3.4

Full-load hammer rate (bpm): 0 - 4000

Full-load speed (rpm): 0 - 900

Max. concrete drilling (mm): 28

Max. steel drilling (mm): 13

Max. wood drilling (mm): 30

Max. drilling in wood/steel/concrete (mm): 30/13/28

Input power (W): 820

Standard equipment: FIXTECTM adapter with keyless chuck

Tool shank: SDS-Plus

Vibration (m/s2): 16

Vibration impact (m/s2): 1.5

Vibration during drilling (m/s2): 22

Weight (kg): 2.9

Sound power level (dB(A)): 103

Sound power level uncertainty (dB(A)): 3

Sound pressure level (dB(A)): 93

Uncertainty of sound pressure level (dB(A)): 3

Vibration drilling in concrete [m/s2]: 22

Uncertainty of vibration drilling in concrete [m/s2]: 1.5
