Bosch GCM 800 SJ 0601B19000 panel saw

Bosch GCM 800 SJ Panel Saw

The Bosch GCM 800 SJ panel saw is a compact stationary tool designed for standard cuts when working with wood and similar materials. The model has a rated power of 1400 W and operates with a 216 mm diameter blade, offering a good balance of performance, portability, and stability during operation. The low weight of 13.5 kg makes it easy to position and transport the machine in a workshop or on a job site. The machine offers a cutting capacity of 70 x 270 mm at 0°, 70 x 190 mm at a 45° bevel, and 48 x 270 mm at a 45° tilt. The bevel adjustment ranges from 47° to the left to 47° to the right, and the tilt can be adjusted up to 45° to the left. The no-load speed reaches 5,500 rpm, which facilitates clean and consistent cutting in typical applications. This model is a suitable choice for users looking for a reliable table saw for paneling with practical dimensions and sufficient capacity for common cutting tasks.

Technical specifications:

• Rated power consumption: 1400 W
• No-load speed: 5500 rpm
• Cutting disc diameter: 216 mm
• Blade bore diameter: 30 mm
• Cutting capacity at 0°: 70 x 270 mm
• Cutting capacity at 45° bevel: 70 x 190 mm
• Cutting capacity at 45° tilt: 48 x 270 mm
• Bevel adjustment: 47° left / 47° right
• Tilt adjustment: 45° left / 0° right
• Weight: 13.5 kg

Included:

• hex wrench
• 216 x 30 mm blade
