Bosch 2608619267 is a pack of 10 cutting discs for stainless steel and metal, 125 x 1 x 22.23 mm, with an X-LOCK fitting and a straight profile. Bosch states up to 1.5 times the life of the standard metal disc 2608619767.

The 1 mm thickness

1 mm is the thin disc. The difference against a standard 2.5 mm is not only speed:

• Less material is removed - less work for the machine and a faster cut at the same power.
• Less heat into the workpiece. On stainless steel that is decisive: overheating burns off the chromium oxide layer that makes it stainless, and the cut starts rusting within weeks.
• A narrower kerf - noticeable when cutting section or tube to a measured length.

The trade-off is that a thin disc is more fragile. It cuts in a straight line only, with no side loading - twisting the grinder in the cut breaks it.

Made for stainless steel

The discs contain less than 0.1% iron, sulphur and chlorine (Fe/S/Cl). This is not a box-ticking spec: residual iron particles from an ordinary disc embed in the cut and then rust on top of the stainless steel, leaving brown speckles across the surface. Low-Fe discs do not have that problem.

Construction

Aluminium oxide grain gives cutting durability, a resin matrix holds the grain and takes the heat, and a strong fibreglass net reinforces the disc. The specification is WA 60 T BF, maximum speed 12,250 rpm at a peripheral speed of 80 m/s.

X-LOCK

X-LOCK is the tool-free disc change system: the disc clicks into place and releases with a lever. An important detail - X-LOCK discs also work on conventional grinders with an M14 threaded spindle and nut, because the bore is the standard 22.23 mm. The reverse is not true: a conventional disc will not lock into an X-LOCK machine.

Making them last

A thin disc is used up in two ways - work and misuse - and the second is far quicker. Three rules cover almost everything.

First: do not push. The disc has its own cutting rate and more pressure does not raise it - it only heats the disc and wears it faster. The right sign is a steady, even spray of sparks, not one thrown a metre across the shop.

Second: cut in a straight line only. Guide the grinder along the axis of the cut; any twist loads the disc sideways, and it is 1 mm thick - that is what breaks discs, not the cutting itself.

Third: do not stop halfway through a deep cut. On re-entry the disc rarely lands exactly in the old kerf and catches on its wall. Better to take the section in one pass, or to open the entry slightly first.
